Vertical Bucket Elevator Machine for gypsum/concrete cement/wood pellet
Bucket Elevator Product Descriptions:
- Bucket elevator use belt as dragging device, it mainly use for conveying material with bulk densityρ<1.5t/m³in vertical direction, which can be powdery material, particles, small lump, less abrasive material.
- Use normal belt, the temperature of conveying material should not exceed 60℃, Use wire belt, conveying material temperature can reach 80℃,use heat resistant belt, material temperature not exceed 150℃, elevating height is 4~30m.
- Normal model of TD type bucket elevator is TD160,TD250,TD315,TD400 etc. conveying capacity is 3.1~66m³/h. which is widely use in chemical engineering, metallurgy, construction material, food, mining industries etc.
Vertical Bucket Elevator Advantages:
- Widely usage, it can elevate powdery material, particles, small lump material.
- Flexible to select mixing or centrifugal discharge method according to material properties.
- Good sealing, no dust escape. Clean and environmental protection.
- Using rubber belt with small dead load, flexible, stable operation, thus elevating speed and process efficiency is higher.
gypsum bucket elevator Equipment Parameters:
| Model | Bucket Type | Capacity (m³/h) | Bucket Width (mm) | Bucket Pitch (mm) | Belt Width (m/s) | Bucket Running Speed (m/s) | Max Size of Material (mm) | Elevating Height (m) |
| TD160 | Q | S | 5~12 | 160 | 400 | 200 | 1.4 | 25 | ≤20 |
| TD250 | Q | S | 20~35 | 250 | 400 | 300 | 1.6 | 35 | ≤30 |
| TD315 | Q | S | 25~40 | 315 | 500 | 400 | 1.6 | 45 | ≤30 |
| TD400 | Q | S | 35~66 | 400 | 500 | 450 | 1.6 | 55 | ≤30 |
FAQ
How to choose the righ type of bucket elevator ?
- The following factors need to be taken into consideration: conveying material, temperature, conveying capacity, working hour, etc.
- We have professional sales manager and engineers who can help you to decide the type.
What about price of bucket elevator ?
- Different models of bucket elevator have different prices.
- We will give you the most favorable price.
- Discount is negotiable.
How about the after-sale installation of bucket elevator?
- Our engineers are aviliable to help you install onsite.
- We also can offer commissioning and operation training service.
